各种螺纹代号的含义（各种螺纹的代号都是什么）

大家好,小东方来为大家解答以上的问题。各种螺纹代号的含义，各种螺纹的代号都是什么这个很多人还不知道,现在让我们一起来看看吧！

1、一、英制螺纹（螺纹牙型角55度）Thread of British standard ( Thread pitch shape angle 55°) BSW－－－－英国标准惠氏螺纹（粗牙）British Standard Whitworth Thread ( Coarse ) BSF－－－－英国标准惠氏螺纹（细牙）British Standard Whitworth Thread ( Fine ) G－－－－直管螺纹（外螺纹分A、B两面级、丝锥分G、G－D）Straight pipe thread ( Outside ) thread in AB: taps in G、G－D ) R－－－－锥管外螺纹（旧代号ZG;KG）Outside paper pipe thread ( Old thread code ZG,KG ) RC－－－－锥管内螺纹（旧代号ZG;KG）Inside taper pipe thread ( Old thread code ZG,KG ) 二、美制螺纹（螺纹牙型角60度）Thread of American standard ( Thread pitch shape angle 60°) UNC－－－－统一制粗牙螺纹（代替NC）Unified coarse pitch thread ( Instead of NC ) UNF－－－－统一制细牙螺纹（代替NF）Unified fine pitch thread ( Instead of NF ) UNEF－－－－统一制超细牙螺纹Unified superfine pitch thread UN－－－－－统一制不变螺距螺纹Unified thread UNS－－－－统一制特殊螺纹Unified Special thread NPT－－－－一般用途锥管螺纹（旧代号Z;K）Taper pipe thread for general purpose ( Old thread code Z,K ) NPSC－－－－管接头直管内螺纹Internal straight pipe thread for connection NPSM－－－－设备上自由配合。

2、机械连接用直管螺纹Straight pipe thread for general purpose NPTF－－－－干密封锥管螺纹Dryseal taper pipe thread NPSF－－－－干密封燃油直管螺纹Dryseal straight pipe internal thread NGT－－－－气瓶用锥螺纹Special thread for gas cylinder 三、米制螺纹Metric thread ZM－－－－－米制锥管螺纹 Metric taper pipe thread 四、其它螺纹Other threads SM－－－－缝纫机螺纹Thread for sewing machine PZ－－－－气瓶用锥螺纹Special thread for gas cylinder 5V1－20V1－气门芯螺纹5V1－20V1－Tyre valve thread 螺纹代号说明示例：Explanation of thread code. e. g. 1/4－20UNC 1/4－公称直径1/4" nominal dia. 1/4" 20－每寸20牙twenty teeth per inch UNC－美标统一制粗牙螺纹unified coarse pitch thread ( American standard。

本文到此分享完毕，希望对大家有所帮助。
